Paperless-ngx

Paperless-ngx is a free document management system with OCR (Optical Character Recognition). It digitizes physical documents and makes them searchable.

YT

Installation

Add the following template to your docker-compose.yml and then run ei23 dc.

Environment file required

Create the file ei23-docker/env/paperless.env before starting.

Create Environment File

Create /home/[user]/ei23-docker/env/paperless.env:

PAPERLESS_SECRET=YOUR_SECRET_TOKEN
PAPERLESS_TIMEZONE=Europe/Berlin
PAPERLESS_OCR_LANGUAGE=eng
PAPERLESS_ADMIN_USER=admin
PAPERLESS_ADMIN_PASSWORD=YOUR_PASSWORD
PAPERLESS_URL=http://your-ip:8010

Secret Token

Generate a secure token: openssl rand -base64 32

Template

  paperlessngx-redis:
    image: redis:7
    container_name: paperlessngx-redis
    restart: unless-stopped
    volumes:
      - ./volumes/paperless/redis:/data

  paperlessngx-db:
    image: postgres:15
    container_name: paperlessngx-db
    restart: unless-stopped
    volumes:
      - ./volumes/paperless/db:/var/lib/postgresql/data
    environment:
      POSTGRES_DB: paperless
      POSTGRES_USER: paperless
      POSTGRES_PASSWORD: paperless

  paperlessngx:
    image: ghcr.io/paperless-ngx/paperless-ngx:latest
    container_name: paperlessngx
    restart: unless-stopped
    depends_on:
      - paperlessngx-redis
      - paperlessngx-db
    ports:
      - "8010:8000"
    volumes:
      - ./volumes/paperless/data:/usr/src/paperless/data
      - ./volumes/paperless/media:/usr/src/paperless/media
      - ./volumes/paperless/export:/usr/src/paperless/export
      - ./volumes/paperless/consume:/usr/src/paperless/consume
    env_file:
      - ./env/paperless.env
    environment:
      PAPERLESS_REDIS: redis://paperlessngx-redis:6379
      PAPERLESS_DBHOST: paperlessngx-db
      PAPERLESS_DBNAME: paperless
      PAPERLESS_DBUSER: paperless
      PAPERLESS_DBPASS: paperless

Features

  • OCR Text Recognition - Searchable PDFs from scans
  • Automatic Categorization - Tags, correspondents, document types
  • Full-text Search - Search in all documents
  • Email Import - Receive documents via email
  • Mobile App - Upload documents on the go
  • REST API - Automation possible
  • Export/Import - Backup and migration

First Start

  1. After starting, Paperless is accessible at http://[IP]:8010
  2. Log in with the credentials configured in the env file
  3. Start uploading documents

Importing Documents

Manually via Web Interface

  1. Click Upload
  2. Select PDF, JPEG, or PNG files
  3. Paperless processes the document automatically

Via the Consume Folder

Place files in the folder ./volumes/paperless/consume/:

# Copy documents to consume folder
cp ~/scans/*.pdf ~/ei23-docker/volumes/paperless/consume/

Paperless monitors this folder and automatically processes new files.

Via Mobile App

  1. Install the Paperless Mobile app
  2. Configure the server URL
  3. Scan documents directly with your phone

Via Email (optional)

Configure in paperless.env:

PAPERLESS_EMAIL_HOST=imap.gmail.com
PAPERLESS_EMAIL_PORT=993
PAPERLESS_EMAIL_USER=your@email.com
PAPERLESS_EMAIL_PASS=YOUR_PASSWORD
PAPERLESS_EMAIL_INBOX=INBOX

Organization

Tags

Tags are freely definable labels:

  • Taxes - Tax documents
  • Insurance - Insurance policies
  • Invoice - Invoices
  • Important - Particularly important documents

Correspondents

Correspondents are senders/recipients:

  • Tax Office
  • Health Insurance
  • Utility Company
  • Employer

Document Types

  • Invoice
  • Contract
  • Notice
  • Letter
  • Pay Slip

Automatic Rules

Paperless can automatically categorize documents:

  1. Go to Settings → Rules
  2. Create a new rule
  3. Define conditions (e.g. text contains "Invoice")
  4. Assign tags/correspondents

Backup

Via the ei23 Script

ei23 backup

Manually

cd ~/ei23-docker/

# Backup database
docker compose exec paperlessngx-db pg_dump -U paperless paperless > ~/Backup/paperless_db.sql

# Backup data
sudo tar -czf ~/Backup/paperless_data.tar.gz volumes/paperless/data/ volumes/paperless/media/

Restore

cd ~/ei23-docker/

# Stop container
docker compose stop paperlessngx

# Restore database
cat ~/Backup/paperless_db.sql | docker compose exec -T paperlessngx-db psql -U paperless paperless

# Restore data
sudo tar -xzf ~/Backup/paperless_data.tar.gz

# Start container
docker compose start paperlessngx

Tips

  • Scan resolution: 300 DPI for good OCR results
  • File format: PDF preferred, TIFF also good
  • Languages: Configure PAPERLESS_OCR_LANGUAGE=eng+deu for English+German
  • Storage: OCR and thumbnails require storage space

Notes

  • Data is located in ./volumes/paperless/
  • Consume folder: ./volumes/paperless/consume/
  • Port: 8010
  • Paperless requires PostgreSQL and Redis
  • For large archives: 4GB+ RAM recommended
